24 x 24 Panel Air Intake Filter Details
The 24×24 Panel Air Intake Filter (DF2424AIP) is a direct replacement option for multiple OEM compressor and blower intake filters, including popular Dollinger, FS Elliott, Ingersoll Rand, and Joy part numbers.
- DAMN Part Number: DF2424AIP
- Filter Type: Industrial Air Intake Panel Filter
- Nominal Size: 24″ x 24″ x 2″
- Actual Size: 23.38″ x 23.38″ x 1.50″
- Media: Synthetic / Polyester
- Media Area: 37.7 sq. ft.
- Frame Material: Galvanized Steel
- Gasket: ½” x ½” neoprene (one face)
- Flow Direction: Outside → In
- Rated Efficiency: MERV 10 / MERV 11 equivalent
- Rated Airflow: 2000 CFM
- Max Operating Temperature: up to 200°F (93°C)
- Construction: Rigid panel design for industrial intake housings
- Recommended Changeout Differential Pressure: 20 PSID
- Sold: 2 per box (price per filter)
This replacement element is engineered to meet or exceed OEM performance for industrial compressor and blower intake applications, delivering reliable efficiency, airflow, and service life.
OEM Cross References for 24×24 Panel Air Intake Filter
Common replacement for the following OEM brands and part numbers:
Keltec
- KA093/509
Air Relief
- 18N00092
Atlas Copco
- 1621-8434-00
Cameron
- AAP0540009-00707
Cameron Compression
- AAP0540009-00289
- AAP0540009-0089
- P5400009-089
- P5400009-189
Complete
- 509-0282
Consler
- 15755
- 15937
- 20523
- 8004
Dollinger
- 3507545
- 3507577
- VE-1103-2424-093
- VE-1103-2424-509
- VE-1103-2424-513
- VE-1113-2424-093
- VE-1113-2424-509
- VE-1113-2424-513
Endustra
- 34093
FS Elliott
- FVE11032424
- P3515A600-1
Hoffman Blower
- 089-6089
Ingersoll Rand
- 1X15233
- 1X2876
- 1X5573
- 1X8258
- 67731166
- 7923093
Joy
- 1663867-0001
- 3606500-0050
- 3606500-12
- 3606500-50
- 527693-0025
- P540009-0089
- P540009-0189
- P540009-0491
Nafco
- PF2201100
- PF2201104
- V-003
Shawndra
- 329-9928
Frequently Asked Questions
- Is this compatible with my OEM housing? If your existing element matches the dimensions and any of the cross reference numbers above, this filter is designed as a direct replacement.
- What efficiency is this? MERV 10 / 11 equivalent, suitable for industrial compressor and blower intake protection.
- How is it sold? Sold in quantities of 2. Pricing shown is per filter.
DAMN Filters offers a full line of replacement filters.
If you don’t see the filter you are looking for or need help give us a call at (844) 605-3266 or contact us.
