Description
DAMN DF3500 Ambient Specs:
- 3500 CFM (max available)
- 16 Gauge Steel
- Sealed cabinet for minimum air bypass
- Filter Change Light
- Easy Access to Filters and other Components
- Heavy-Duty, Motor/Blower Combination
- 4-Way Adjustable Grill
- Cabinet: 16 Gauge Welded Galvanealed Steel
- Finish: Industrial Grade Textured Baked Enamel inside and out
- Cabinet Dimensions: 26”H X 26” W X 69” L
- Blower/Motor Assembly: 1.5 HP, 120 Volt, 60 HZ, Thermally Protected Ball Bearing Motor
- Controls: single phase, 120 volt models come standard with 10’ power cord and on/off switch
- Electrical: 120 volt, 60 hz cord with standard plug, maximum 17.2 amps
- Rated Fan Performance: 3500 CFM Single Speed
- Standard Weight: 268 LBS Actual; 300 LBS Shipping
- Noise Level: 76 DBA (Optional Silencer Available)
- Filters: 4” Pleated Pre-Filter; Merv 14 Bag Filter
DAMN 3500 Applications:
- Laser Fumes
- Laser Printing
- Chemical Fume Removal
- Cleaning with Solvents
- Grinding
- Welding
- Toxic Fumes/Powders
- Adhesive Glue Fumes
- Polishing Applications
- Sanding Operations
- Powder Weighing
- Robotic Welding
- Small Grinding Operations
All equipment purchases require 50% down payment.
DAMN Filters offers a full line of dust collection equipment.
If you don’t see the dust collector you are looking for or need help give us a call at (844) 605-3266 or contact us.
Explore more from our collection.
