High-Efficiency 24×24×12 HEPA Air Filter — 99.99% Particle Capture, Micro-Glass Filtration, Durable ABS Plastic Frame, 6-Volt Ready

Description

HEPA Filter 6V Details

The HEPA HV filter is designed for high air volume capacity, using micro glass fiber paper media in a minipleat V-bank construction. It features a plastic frame, and is individually scan-tested per EN 1822 standards for leak-proof performance. The V-shaped mini-pleat design maximizes airflow, reduces pressure drop, and extends filter life, with mounting options for various air handling units.

HEPA Specs:

• HEPA 6V Filter
• Part Number: HX6H11APN1D3
• Size: 24 x 24 x 12 (610x610x292)
• Efficiency: 99.99% / H13
• Media: Micro Glass
• Frame: ABS Plastic (6V)
• Neoprene Gasket on downstream side
• Rated Airflow: 2400 CFM
• Initial Pressure Drop: 1.15” Wg
• Final Pressure Drop: 2” Wg
• Packing: 1 piece per box

Cross Reference: RP EXF-1151-11, Total Finishing TFSFJ-HEPA-24x24x12, Mikropor MVH-610/610/292-13GD-40M2, Mikropor MVH-610/610/292-13PKD

DAMN Filters offers a full line of HEPA filters.

HEPA Data Sheet

If you don’t see the HEPA filter you are looking for or need help give us a call at (844) 605-3266 or contact us.
