Description
IF614 Filter Specs
This filter features premium resin-impregnated cellulose media for economical filtration and high dirt-holding capacity, with electroplated steel components and Buna-N gaskets for a reliable seal. It withstands up to 150 psi, handles temperatures to 225°F, and outperforms major competitors in service life and particle removal. Ideal for lubricating oils, hydraulic fluids, cutting fluids, coolants, process water, wastewater, and gasoline.
- Measurements: Diameter – 6” (152 mm), Length – 14” (356 mm), ID – 2.62” (73 mm)
- Filter Media: Resin Impregnated Cellulose
- Nominal Micron Rating: 0.5, 1, 5, 10, 20
- Outer Body: Perforated Tin-Plated Steel
- Top Caps: Tin-Plated Steel
- End Caps: Tin-Plated Steel
- Gasket / Grommet Type: Nitrile/Buna-N
- Handle: Yes
- Configuration: Double Open Ended
- Direction of Flow: Outside → Inside
- Type of Adhesive: Polyurethane
- Inner Center Core: Louvered Tin-Plated Steel
- Recommended Change Out: 35 PSID
- Maximum Operating Pressure: 100 PSI
- Maximum Temperature: 225°F
- Made in the USA
Target machine and filtration systems
- Honing Machines
- Grinders – EWAG, Makino, Studer, Hardinge, Kaast Surface Grinders, etc.
- Cold Heading and Machine Tool Coolant Applications
- Screw Machine Oil Reclaim Systems
- Machines using Hydraulic Fluid and Machining Fluids such as Water Glycols and Coolants
- Machines that Filter Diesel, Gasoline, and other Fuels including Lubricating Oils, Synthetic Lubricants, and Process Fluids
- Water or Oil Filtration Systems – Ebbco, Shelco, Harmsco, MSC Filtration carts, and other systems using cartridge vessels
DAMN Filters offers a full line of Hydraulic filters.
If you don’t see the Hydraulic filter you are looking for or need help give us a call at (844) 605-3266 or contact us.
