Description
ASHRAE Cell Filter Specifications
The ASHRAE Cell is a high-efficiency extended surface deep pleat filter designed for demanding applications such as VAV systems, turbulent airflow, and high humidity environments. Its rigid construction and aluminum separator design help prevent dust unloading and support stable performance throughout the filter’s service life.
This deep pleat ASHRAE cell filter is commonly used as a direct replacement for traditional pocket or bag filters where durability, space efficiency, and extended service life are required.
- OEM Make: DAMN Filters
- Part Number: DF202012ASH
- Filter Category: High-efficiency ASHRAE deep pleat cell filter
- ASHRAE 52.2 Rating: MERV 14
- Nominal Size: 20 x 20 x 12 in
- Actual Dimensions (in): 19.38 W x 19.38 H x 11.50 D
- Nominal Depth: 12 in
- Filter Media: Micro fine glass media
- Media Separators: Aluminum corrugated separators
- Frame: Galvanized steel construction
- Typical Operating Airflow: up to 1,300 CFM (application dependent)
- Typical Initial Resistance: approximately 0.60 in. w.g. at rated airflow
- Recommended Final Resistance: 1.40 in. w.g.
- Maximum Operating Temperature: 80°C / 176°F
- Gasket: Optional seamless PU gasket
- Recommended Use: Final filter in commercial HVAC systems or prefilter to HEPA
Applications
- Hospitals and healthcare facilities
- High-tech and electronics manufacturing
- Semiconductor fabrication
- Biomedical and pharmaceutical facilities
- Laboratories and research environments
- Food processing facilities
- Universities and institutional buildings
- Biotechnology and genetic research
Available configurations include single header, double header, or box-style frame construction with optional gasket sealing depending on housing requirements.
OEM Cross Reference (for reference only):
- Filtration Manufacturing: 0902-202012-8-NH, 0902-202012-8-SH, 0902-202012-8-DH
- Variflow: SC 2900629
- Cary Company: 21BF75
- Grainger / Air Handler: 5W918
- Zoro: G0298283
- Koch Filter: FM 110-729-998
If you don’t see the filter you are looking for or need help confirming fit, give us a call at(844) 605-3266 or contact us.
Metafield Description:
MERV 14 ASHRAE deep pleat cell filter, 20x20x12, extended surface micro fine glass media with aluminum separators. Designed for commercial HVAC final filtration or prefilter to HEPA.
